KG316T Timer

KG316T Timer

The KG316T is a digital programmable time switch designed for automatic control of electrical loads based on scheduled time settings. It allows users to set multiple ON/OFF programs within a 24-hour or weekly cycle, making it ideal for lighting systems, water heaters, pumps, advertising boards, and automation systems.

The device integrates an internal relay and LCD display, offering precise timing control for residential, commercial, and light industrial applications.

Technical Specifications

Parameter Specification
Model KG316T
Product Type Digital Timer Switch
Mounting DIN Rail
Display LCD Screen
Programming Type Daily / Weekly Timer
Number of Programs Up to 16 ON/OFF programs
Backup Battery Built-in rechargeable battery
Minimum Setting Interval 1 minute

Electrical Ratings

Parameter Specification
Rated Voltage 220 – 240 V AC
Rated Frequency 50 / 60 Hz
Rated Load Current 16 A
Maximum Load Power 3500 W (Resistive load)
Contact Type 1NO (Single channel output)
Insulation Voltage 250 V

Timing Functions

Function Description
24-Hour Mode Daily repeating schedule
Weekly Mode 7-day programmable schedule
Manual Override ON / AUTO / OFF modes
Countdown Supported
Automatic Repeat Yes

Environmental Conditions

Parameter Specification
Operating Temperature −10 °C to +50 °C
Storage Temperature −20 °C to +60 °C
Humidity ≤ 95 % (non-condensing)
Protection Degree IP20

Typical Applications

  • Lighting control systems
  • Water heater automation
  • Garden irrigation systems
  • Advertising sign control
  • HVAC timing control
  • Pump timing systems
